How to Install Rancho® RS5000®X Shocks
CROSS TUNED TECHNOLOGY
Packed with innovative features, Rancho® RS5000®X shocks deliver improved overall on- and off-road handling and performance thanks to Rancho’s exclusive Cross Tuned technology. Developed by the ride engineers at Rancho, this unique and exclusive rebound valving system and advanced compression phase of the shock absorber is at the heart of the RS5000X. Read on to learn how to install this shock to deliver improved overall on- and off-road handling and performance.
INSTALLING THE RS5000X SHOCK
Installing the Rancho RS5000X is straightforward job for both technicians and DIYers. Before jumping into the repair, take the time to complete some basic safety steps to get ready for the job.
Step 1 – Stay Safe
Be sure to follow these tips to ensure that you complete the job safely.
- Park vehicle on a flat, level surface.
- Chock the rear tires in the front and back to ensure the vehicle doesn’t roll forward or backward.
- Set the parking brake for an extra measure of safety.
- If using jack stands, position them under the frame where you’re working. If installing a front shock, put jack stand under the front frame and not under the front control arm.
Step 2 – Remove Tire
To get started, remove the vehicle’s tire. In some cases, you may not need to remove the tire to get access to the shock.
Step 3 – Remove Old Shock
Locate and remove the bolts at the top of the shock. Also remove the bolt that goes through the shock. Once the bolts are removed, take the old shock out.
Step 4 – Install New Shock
With the old shock out of the way, it’s time to install the new Rancho RS5000X shock. Position the new shock and then install the bolts. Torque the upper nuts and lower bolt to manufacturer specifications. Be sure to reference your owner’s manual or the technical manual for your vehicle.
Step 5 – Replace Tire
Finish up the repair by putting the tire back on and torque it back to manufacturer specifications (if you removed it).
RS5000X SHOCK FEATURES
IMPROVED HANDLING AND PERFORMANCE -- Cross Tuned technology featuring exclusive rebound valving system and advanced compression phase improves overall handling and performance on- and off-road
MINIMIZES ROUGH RIDE -- Exclusive Progressive Engagement Valving is custom-tuned for each vehicle to help reduce initial impacts at low speeds and minimize a rough ride
STRONG AND DURABLE -- Features a 16mm nitro-carburized piston rod to resist scuffs and corrosion, double-welded loops at stress areas, 35mm sintered iron piston for enhanced structural integrity and polyvinyl protective boot
HANDLES EXTREME TEMPERATURE CHANGES -- Large twin-tube body filled with all-weather fluid allows for cooler operation, increased vehicle control and ability to withstand internal temperatures of -40 to 248°F
SMOOTH PERFORMANCE -- Polyurethane rebound bumper and rubber bushings help absorb ride harshness, while the fluon-banded piston enhances responsiveness to changing road conditions for an overall smoother ride
RANCHO RS5000X SHOCKS
|
Year |
Make/Model |
Part Number - Location |
|---|---|---|
|
2018-present |
Jeep Wrangler JL |
RS55063 - Front RS55064 - Rear |
|
2020-present |
Jeep Gladiator JT |
RS55063 - Front RS55069 - Rear |
|
2007-2018 |
Jeep Wrangler JK |
RS55326 - Front RS55328 - Rear |
|
2014-2020 |
RAM 2500/3500 4WD |
RS55197 - Front RS55044 - Rear |
|
2015-2020 |
Ford F-150 4WD |
RS55836 - Front RS55316 - Rear |
|
2014-2018 |
Chevrolet Silverado/GMC Sierra 1500 2WD/4WD |
RS55830 - Front RS55198 - Rear |
|
2011-2020 |
Chevrolet Silverado/GMC Sierra 2500/3500 |
RS55377 - Front RS55379 - Rear |
Learn more about performance shocks, find your performance suspension part, or find where to buy your shock or suspension part today.
